Data network cables & components

MSG offer variety of the most common data network brands, in the Egypt’s consultant vendor lists for small and mega projects in Egypt,

• Commscope Systimax
• Legrand
• Nexans
• Panduit
• Corning
• Leviton

 MSG not only offers cables, we offer a full passive solution for your project, cables and accessories, all passive network components with technical support and full documentation.

CommScope’s SYSTIMAX portfolio provides high-performance structured cabling, featuring GigaSPEED copper solutions for Cat6/6A and LazrSPEED or TeraSPEED for fiber optic networks. These systems are designed to exceed industry standards, offering higher bandwidth and easier installation for enterprise and data center environments. CommScope +4

SYSTIMAX Cat6 & Cat6A Copper Solutions

CommScope’s copper offerings focus on reliability and future-proofing through advanced crosstalk reduction and high-speed data support. CommScope +4

• GigaSPEED XL (Category 6): Designed for gigabit applications, these cables exceed standard Cat6 requirements by providing 1dB of extra headroom for crosstalk. They support 1 Gbps up to 100 meters and can handle 10 Gbps for shorter distances (typically up to 55m).
• GigaSPEED X10D (Category 6A): Specifically engineered for 10 Gbps Ethernet, this solution maintains full performance over the entire 100-meter channel. It features enhanced shielding (GigaSHIELD) and tighter twists to eliminate “alien crosstalk” in high-density environments.
• GigaREACH XL: An extended-reach solution that supports 100 Mbps and 90W PoE at distances up to 200 meters, effectively doubling the standard 100m limit for non-standard links. CommScope +6

SYSTIMAX Fiber Optic Solutions

SYSTIMAX fiber solutions are divided by mode and speed requirements, often utilizing the InstaPATCH 360 pre-terminated system for rapid deployment. CommScope

• LazrSPEED (Multimode): Optimized for short-to-medium distances in data centers. For instance, LazrSPEED 550 (OM4) supports 100 Gbps speeds up to 150 meters.
• TeraSPEED (Singlemode): Designed for long-haul and campus backbones, these OS2-rated fibers can support 40G/100G Ethernet over distances up to 200km.
• Propel Portfolio: A high-density fiber platform featuring 8-, 12-, 16-, and 24-fiber connectivity to support rapidly evolving network architectures. CommScope +4

Key Performance Specifications

According to CommScope‘s official product documentation:

• Bandwidth: SYSTIMAX Cat6 operates at 250 MHz, while Cat6A doubles this to 500 MHz.
• PoE Support: Both copper lines fully comply with IEEE 802.3bt (Type 4) for delivering up to 90W of power over LAN cables.
• Environmental Ratings: Cables are available in various jacket types, including Plenum (CMP) for air-handling spaces and Low Smoke Zero Halogen (LSZH) for reduced toxicity during fires. CommScope +4

CommScope SYSTIMAX network components comprise a comprehensive range of copper and fiber optic solutions designed for high-performance enterprise structured cabling. The portfolio is organized into specialized brands like GigaSPEED XL for Category 6 copper and LazrSPEED or TeraSPEED for fiber. CommScope +1

SYSTIMAX Category 6 (Copper) Components

These components are primarily part of the GigaSPEED XL and GigaREACH XL lines, supporting speeds up to 1 Gbps and extended distances beyond standard limits. CommScope

• Twisted Pair Cables: Includes unshielded (U/UTP) and shielded options with various jacket materials like LSZH (Low Smoke Zero Halogen) or Plenum. Examples include the GigaSPEED XL® 3071E-UTG and the GigaREACH XL Category 6 UTP which supports 1 Gbps up to 150 meters.
• Copper Patch Panels: High-density termination solutions such as the SYSTIMAX® M-series 24-port UTP Patch Panel and the SYSTIMAX 360™ GigaSPEED X10D® Panels.
• Modular Jacks and Connectors: Includes RJ45 outlets and information outlets used in work area faceplates.
• Patch Cords: Factory-terminated cables for equipment connections, such as the GigaSPEED XL® CPC3312 RJ45 Patch Cord.

SYSTIMAX Fiber Optic Components

The fiber portfolio includes LazrSPEED (Multimode OM3/OM4/OM5) and TeraSPEED (Singlemode OS2) solutions. CommScope +1

• Fiber Optic Cables: A range of indoor, outdoor, and indoor/outdoor cables, such as the LazrSPEED® OM4 2-fiber Zipcord.
• Patch Panels and Enclosures: Modular frames like the FPX series and Propel™ panels for high-density fiber management in data centers.
• Fiber Patch Cords: Duplex and simplex cords with various connector interfaces (LC, SC, MPO), such as the InstaPATCH® 360 Duplex Fiber Patch Cord.
• Modules and Cassettes: Pre-terminated fiber modules like Propel™ and InstaPATCH® that allow for rapid plug-and-play deployment. CommScope +6

Management and Accessories

• Cable Management: Vertical and horizontal hardware for organizing cables in racks and cabinets.
• Faceplates and Boxes: Workstation outlets for terminating copper and fiber cables at the user end.
• imVision® Intelligence: An automated infrastructure management (AIM) system for real-time monitoring of physical layer connections. CommScope +4
